Product Type

PG-22
Precision Planetary Gearbox

PG-22

Outer diameter(mm)：22 Reduction ratio：1/4 - 1/308 Max. rated torque(N-m)：0.53 - 0.71
more
PG-32
Precision Planetary Gearbox

PG-32

Outer diameter(mm)：32 Reduction ratio：1/4 - 1/308 Max. rated torque(N-m)：0.66 - 3.92
more
PG-32LN
Precision Planetary Gearbox

PG-32LN

Outer diameter(mm)：32 Reduction ratio：1/14 - 1/308 Max. rated torque(N-m)：1.96 - 3.92
more
PG-42
Precision Planetary Gearbox

PG-42

Outer diameter(mm)：42 Reduction ratio：1/4 - 1/308 Max. rated torque(N-m)：2.65 - 13.23
more
PG-42LN
Precision Planetary Gearbox

PG-42LN

Outer diameter(mm)：42 Reduction ratio：1/4 - 1/393 Max. rated torque(N-m)：2.65 - 13.23
more
PG-52
Precision Planetary Gearbox

PG-52

Outer diameter(mm)：52 Reduction ratio：1/4 - 1/308 Max. rated torque(N-m)：3.92 - 24.5
more
PG-52LN
Precision Planetary Gearbox

PG-52LN

Outer diameter(mm)：52 Reduction ratio：1/4 - 1/393 Max. rated torque(N-m)：3.92 - 24.5
more
IG-06
Planetary Gearbox

IG-06

Outer diameter(mm)：6 Reduction ratio：1/4 - 1/256 Max. rated torque(N-m)：0.002 - 0.02
more
IG-08
Planetary Gearbox

IG-08

Outer diameter(mm)：8 Reduction ratio：1/4 - 1/4096 Max. rated torque(N-m)：0.0049 - 0.04
more
IG-10
Planetary Gearbox

IG-10

Outer diameter(mm)：10 Reduction ratio：1/4 - 1/4096 Max. rated torque(N-m)：0.0049 - 0.06
more
IG-12
Planetary Gearbox

IG-12

Outer diameter(mm)：12 Reduction ratio：1/4 - 1/4096 Max. rated torque(N-m)：0.08 - 0.2
more
IG-13
Planetary Gearbox

IG-13

Outer diameter(mm)：13 Reduction ratio：1/4 - 1/4096 Max. rated torque(N-m)：0.08 - 0.2
more
